Vertica

Choose a variant
VERTICA SOCKET
Black anodised aluminium
VERTICA SOCKET
Silver anodised aluminium
VERTICA CABLE
Black anodised aluminium
VERTICA CABLE
Silver anodised aluminium
Specification
VERTICA Socket
Basic information
Housing
Anodised aluminium / black / silver
Power supply type
AC
Connector type
2 x socket outlet with Type 2 lock
Charging current / power
2x 1.4 kW — 22 kW
Height
1310 mm
Diameter
250 mm
Spiral cable (maximum length)
NO
Connections
OCPP protocol
Offline / WiFi, Ethernet, LTE (GSM) requires Bridge module
User Interface
OLED graphic display / RFID / 2 buttons
Network device capable
Built-in – Enelion Chain
Parameters
Electricity meter
Integrated 3-phase energy meter
Energy meter MID
Optional — integrated in the device
Degree of impermeability
IP 54
Impact protection degree
IK 10
Residual current protection
RCM B / RCD A / RCD B (optional)
Dynamic load balancing (DLB)
Enelion DLB (optional)
Operating temperature
-25°C / +55°C
Product sheet
Specification
VERTICA Socket
Basic information
Housing
Anodised aluminium / black / silver
Power supply type
AC
Connector type
2 x socket outlet with Type 2 lock
Charging current / power
2x 1.4 kW — 22 kW
Height
1310 mm
Diameter
250 mm
Spiral cable (maximum length)
NO
Connections
OCPP protocol
Offline / WiFi, Ethernet, LTE (GSM) requires Bridge module
User Interface
OLED graphic display / RFID / 2 buttons
Network device capable
Built-in – Enelion Chain
Parameters
Electricity meter
Integrated 3-phase energy meter
Energy meter MID
Optional — integrated in the device
Degree of impermeability
IP 54
Impact protection degree
IK 10
Residual current protection
RCM B / RCD A / RCD B (optional)
Dynamic load balancing (DLB)
Enelion DLB (optional)
Operating temperature
-25°C / +55°C
Product sheet
Specification
VERTICA Cable
Basic information
Housing
Anodised aluminium / black / silver
Power supply type
AC
Connector type
2 x cable with Type 2 plug
Charging current / power
2x 1.4 kW — 22 kW
Cable length
4 m (spiral)
Height
1310 mm
Diameter
250 mm + cable
Connections
OCPP protocol
Offline / WiFi, Ethernet, LTE (GSM) requires Bridge module
User Interface
OLED graphic display / RFID / push buttons
Network device capable
Built-in – Enelion Chain
Parameters
Electricity meter
Integrated 3-phase energy meter
Energy meter MID
Optional — integrated in the device
Degree of impermeability
IP 54
Impact protection degree
IK 10
Residual current protection
RCM B / RCD A / RCD B (optional)
Dynamic load balancing (DLB)
Enelion DLB (optional)
Operating temperature
-25°C / +55°C
Product sheet
Specification
VERTICA Cable
Basic information
Housing
Anodised aluminium / black / silver
Power supply type
AC
Connector type
2 x cable with Type 2 plug
Charging current / power
2x 1.4 kW — 22 kW
Cable length
4 m (spiral)
Height
1310 mm
Diameter
250 mm + cable
Connections
OCPP protocol
Offline / WiFi, Ethernet, LTE (GSM) requires Bridge module
User Interface
OLED graphic display / RFID / push buttons
Network device capable
Built-in – Enelion Chain
Parameters
Electricity meter
Integrated 3-phase energy meter
Energy meter MID
Optional — integrated in the device
Degree of impermeability
IP 54
Impact protection degree
IK 10
Residual current protection
RCM B / RCD A / RCD B (optional)
Dynamic load balancing (DLB)
Enelion DLB (optional)
Operating temperature
-25°C / +55°C
Product sheet
Useful files
ENELION VERTICA
Assembly Instruction
09.05.2024
Download
ENELION VERTICA
User Manual
09.05.2024
Download
ENELION VERTICA
Product Sheet
09.05.2024
Download
ENELION VERTICA SOCKET
Technical Sheet
19.03.2024
Download
ENELION VERTICA CABLE
Technical Sheet
19.03.2024
Download
DealerToolbox Manual
27.03.2024
Download
DealerToolbox for Windows
18.10.2022
Download
DealerToolbox for Linux
18.10.2022
Download
ENELION VERTICA
EU Declaration of Conformity
22.04.2024
Download
ENELION VERTICA
REACH Declaration of Conformity
23.04.2024
Download
ENELION
UKCA Declaration of Conformity
03.02.2023
Download
ENELION
UE IK 10 and IP 54 Declaration
03.02.2023
Download
Archive
